The high levels of torque from this robust 15KW/20hp unit mean that it can handle greater volumes of plastic items such as CDs/DVDs/ video cassettes, plastic bottles and containers and PET drinks bottles than the U-7.
In addition, its low speed/high torque combination means that the U-15 can shred heavier duty products such as some plastic utility piping, plastic extrusions, injection mouldings and rotational mouldings.
| Height | Width | Length | Weight | |
|---|---|---|---|---|
| General Assy | 2400mm | 1125mm | 2180mm | 1200kg |
| Shredder | 550mm | 750mm | 2100mm | 800kg |
| Drive Motor | 550mm | 475mm | 1150mm | 325kg |
| Safety Stand* | 1175mm | 875mm | 2180mm | 300kg |
| Safety Hopper* | 920mm | 950mm | 765mm | 70kg |
| Control Panel | 600mm | 600mm | 200mm | 30kg |
| Cutting Chamber Size | 700mm x 345mm |
|---|---|
| Distance between shaft centres | 132mm |
| Size of shaft hexagon | 60mm A/F |
| Maximum knife diametre | 175mm |
| Maximum knife thickness | 31mm |
| Maximum weight of knife | 5kg |
